Once EcoTec FloorFoam is installed use a tape measure to measure the the total area of he room, You should measure the width and length.

You should begin laying SPC-Lux Flooring in theback corner of the room. We recommend starting will a fullboard and cut the final piece of the run down to size. This will create a scattered pattern.

We have provided a Set Square and Knife with the SPC-Lux Flooring Kit to ensure you create a perfect straight edge. Score a straight line with the Knife and Set Square then you can simply snap the board. Installation Tip: Do not cut a board directly on top of a board that has already been laid, you can risk scraping it. You can cut it in another area of the room or use an unused board as a base to work on.

SPC-Lux Flooring boards have been designed with the UNILINC Locking System that simply click together. You can feel the boards click into place this makes installation much easier.

Your kit also includea a Mallet and Tapping Block to ensure each board us secure. The Maller is rubber and will not damage the SPC-Lux Flooring

There is a Profile Gauge in the kit, this replicates shapes of doorways and other tricky shapes. This will allow you to replicate the same shape on the SPC-Lux Flooring. You simply push the Gauge against the shape you're wanting to recreate and mark the shape on the flooring board. This shape can be cut using a jigsaw.

When you get to the edge of the room you can use the Pull Bar to ensure the flooring is secure and the the UNILINC System is in place. You can go all around the perimeter of the room using the Pull Bar in conjunction with the Mallet.

If you're fitting SPC-Lux Flooring around radiator pipes use the Profile Gauge and push it against the radiator until halfway and draw this shape on the end of a board. Do the same with the board placed on the other side of the radiator pipe. Use the jigsaw to cut the shape out and slot each piece of the flooring around the pipe and it should slot into place. You can finish this off with pipe covers.

Roll the EcoTec Floor Foam out on to your timber floor. This can be rolled either vertically or horizontally, whatever your preference is!

You can then cut the EcoTec Floor Foam, when you arrive at the end of your run. You can either with our Multifoil Scissors or a Cutting Knife (both of these products are included in our Multifoil Fitting Kit). Keep insulating in strips until the full floor area you wish to insulate is covered. You can also make little cuts where the radiator pipes etc. are if required - just try and ensure you have a continous layer where possible.

Once cut to size, you can then Staple EcoTec FloorFoam on your timber floor, we advising leaving around a 30cm gap between each staple to ensure the material is secure.

Ensure FloorFoam Insulation is butt jointed together by this we mean, so not overlap so you have a double layer at any point. Then, use the Thermaseal Foil Joining Tape, that is provided alongside the EcoTec Floor Foam, to seal all around the edges (peremiter) and the joints. The Thermaseal Foil Joining Tape used to do this is provided within the kit. Taping and sealing ensures no draught or moisture can rise up through the floor.

Finally, once installed and fully taped and sealed and secure - you can now proceed to install your desired flooring. If carpet is installed, the use of an underlay is advised prior to the carpet. Laminate or wood floors can be installed directly on top of FloorFoam. If a vinyl or lino is being used, we would advise the use of a plywood over the top of the FloorFoam.

Start by rolling out FloorFoam Insulation either vertically or horizontally on the concrete floor. EcoTec FloorFoam can then easily be cut by using Multifoil Scissors or a Cutting Knife - Both available in our Fitting Kit.

FloorFoam is fixed onto concrete floors by using Thermaseal Double Sided Tape, or Non-Solvent Glue. Ensure FloorFoam Insulation is fully taped and sealed on butt joints on the floor. Also tape FloorFoam around the perimeter.(Thermaseal Foil Tape is provided free of charge in kit). Taping and sealing ensures no draught or moisture can rise up through the floor.

Once your concrete floor has been covered with FloorFoam, next you can install your desired flooring. Wood & laminate flooring can be installed directly on top of FloorFoam. We recommend to use a carpet underlay prior to a carpet being installed. If a vinyl or lino is being used, we would advise the use of a plywood over the top of the FloorFoam.
